The best of both worlds
The Merger Duo NXP50 introduced Pulsar’s first pair of multispectral binoculars. Designed to offer the detection capabilities of a thermal imaging device and the identification capabilities of a digital night vision device, these intuitive binoculars will enhance your day- and night-time observation efforts — providing a crystal-clear thermal image through the thermal channel and excellent levels of information through the digital channel.
The Merger Duo NXP50 is perfect for several applications:
- A powerful thermal sensor ensures extreme thermal sensitivity, making it ideal for use in any weather conditions and at various distances.
- A full-HD ultra-low-light CMOS sensor will reveal important anatomical details of an observed animal.
- Combined viewing mode via Picture-in-Picture (PiP) combines both thermal and digital channels, enabling better situational awareness.
Compare Models
PULSAR MERGER
DUO NXP50
The Merger Duo NXP50 provides users with the detection capabilities of a powerful thermal imaging device and the identification capabilities of a fully-fledged digital night vision device. Plus, with combined viewing mode and Picture-in-Picture, users can even evaluate the terrain around them via the digital night vision channel whilst identifying an observed animal’s anatomical features through the thermal channel.
Main Specifications:
| Thermal Sensor | 640×480, 17µm, <25mK NETD |
| Digital Sensor | 1920×1200 Full-HD CMOS |
| Objective Lens | 50mm f1.0 (thermal) | 50mm f1.4 (digital) |
| Magnification | 3-24x (thermal) | 1.5-12x (digital) |
| FOV | 12.4×9.3 / 21.8×16.4 (thermal) | 21.1×16.3 / 16.4×12.3 (digital) |
| Detection Range | 1800m (thermal) |
Unprecedented thermal
performance
The Merger Duo NXP50 features a highly sensitive 640×480, 17 µm, <25mK NETD, detecting even the smallest heat signature at a range of up to 1800m. This sensor, combined with an extremely powerful 50mm f1.0 germanium objective lens, achieves the stunning thermal optics that have become synonymous with the Pulsar name. The Merger Duo NXP50’s <25mK NETD rating provides exceptional thermal sensitivity, ensuring the image presented is always crystal-clear, regardless of weather and environmental conditions.
Full-HD digital
night vision
Using a powerful 1920x1200px CMOS sensor, the Merger Duo NXP50 will achieve a stunning digital night vision image with high-quality detail processing ensuring users can never miss any detail. This night vision channel will effortlessly highlight an observed animal’s silhouette, anatomical features, and behavioural peculiarities, providing greater information in the field and enabling improved decision making.
Enhanced night-time
detection with included
IR illuminator
Increasing both the image detail and detection capabilities in the digital channel, the Merger Duo NXP50 is provided with an invisible 940 nm IR illuminator as standard. This IR illuminator can be seamlessly integrated to the underside of the device. Three-step power adjustment allows users to choose their preferred viewing distance and improve the illumination distance when viewing objects or animals in low-light conditions. Plus, the ability to make minute adjustments to the IR illuminator’s spot position adds a greater level of observational control, making it possible to place the highest levels of illumination in desired areas in the FOV.
Ergonomic carry
case provided
A sleek and ergonomically designed carry case is provided, providing a comfortable way in which to stow the device when it is not in use. Provided with multiple interchangeable straps, including a neck strap and a harness, this case is designed to maintain excellent levels of comfort in the field, without affecting your mobility or range of motion. Convenient straps on the back of the carry case even allow it to be attached to a belt or to gear with a modular Molle fixation, such as backpacks or webbed gear.
The Merger Duo NXP50 also features:
Choose from a selection 8 colour palettes
Built-in video recorder with audio & still imaging capture
Ergonomically designed carrying case provided
Robust & durable magnesium alloy bodyshell
Extreme operating temperatures (from -25 to +50°C)
Stream Vision 2 app compatibility
Battery-saving proximity sensor
Combined viewing mode with Picture-in-Picture (PiP)
Improved Wi-Fi connectivity (2.5/5 GHz)
Advanced image processing algorithms
Dual battery system: up to 7 hours battery life
Comfortable ergonomic design
Adjustable interpupillary distance
Tripod mountable
IPX7 waterproof
